UNS S32760 Flanges Manufacturer in India
UNS S32760 flanges are high-grade super duplex stainless steel components engineered for extreme service conditions where both mechanical strength and corrosion resistance are critical. This grade is commonly known as Zeron 100, offering an advanced combination of chromium, molybdenum, tungsten, and nitrogen that significantly enhances performance in aggressive environments.
One of the key advantages of UNS S32760 flanges is their outstanding resistance to pitting, crevice corrosion, and stress corrosion cracking, especially in chloride-rich and seawater applications. Because of this, they are widely used in offshore oil and gas platforms, subsea pipelines, desalination plants, chemical processing units, and marine engineering systems.
UNS S32760 Flanges, ASTM A182 F55 Material, ASME B16.5 / B16.47 Standard Weld Neck Flange, Slip-On Flanges, Blind Flanges, Threaded Pipe Flanges with Tested Quality
These flanges are available in different types such as weld neck, slip-on, blind, socket weld, threaded, and lap joint. Each type is selected based on system design, pressure requirements, and installation needs. Weld neck flanges are preferred for critical high-pressure pipelines, while slip-on and threaded flanges are commonly used in less demanding connections.
Industries We Serve - UNS S32760 Super Duplex Steel Flanges
These flanges are extensively used across industries like oil and gas, petrochemical processing, offshore engineering, desalination plants, marine systems, and power generation facilities. Their high mechanical strength and durability, they allow engineers to build more efficient piping systems with reduced weight while still maintaining full structural safety. This not only improves overall system performance but also helps lower material consumption and long-term operational costs.
Buy UNS S32760 Class 150 Flanges in Mumbai, Trusted Supplier of ASTM A182 F55 Material with ASME B16.5 and DIN Standard Flanges with Fast Delivery and Competitive Rates.
UNS S32760 flanges are manufactured under strict quality control using forging, machining, and heat treatment processes to ensure uniform structure and reliable performance. Proper processing helps maintain corrosion resistance and mechanical stability even in harsh operating conditions.
Check Latest UNS S32760 Flanges Chemical Composition
| Element | Composition (%) |
|---|---|
| Chromium (Cr) | 25.5 |
| Nickel (Ni) | 6.4 |
| Molybdenum (Mo) | 3.5 |
| Copper (Cu) | 0.75 |
| Nitrogen (N) | 0.25 |
| Tungsten (W) | 0.75 |
| Silicon (Si) | 1.00 |
| Manganese (Mn) | 1.00 |
| Phosphorus (P) | ≤ 0.030 |
| Sulfur (S) | ≤ 0.010 |
| Carbon (C) | ≤ 0.030 |
| Iron (Fe) | Balance |
Super Duplex Steel UNS S32760 Flanges Specifications
| Specification Chart Of : UNS S32760 Flanges | |
|---|---|
| Bore Diameter | NPS ≤ 10 |
| Approved Standards | API 7S-43, API 605, BS 4504, EN 1092, UNI, ANSI/ASME B16.5, API 7S-15, IS 2062, ISO 7005-1, MSS SP-44, ASME B16.48, AWWA C207, ASME B16.36, DIN, BS 1560-3.1, B16.47 Series A & B |
| Pressure Rating | 150 LBS to 2500 LBS |
| Flange Face Types | RTJ, FF, Raised Face, Lap Joint, Tongue & Groove (Large & Small), Male-Female (Large & Small) |
| Manufacturing Process | Forged, Heat Treated & Machined |
| Size Range | 1/2 Inch to 48 Inch |
| Flange Types | Forged / Plate / Threaded |
| Common Types | Weld Neck, Slip-On, Blind, Socket Weld, Threaded, Lap Joint |
| Applications | Oil & Gas, Power Plants, Nuclear Power, Waterworks, Municipal Systems, Food Processing, Fossil Fuel Plants |
| High Temperature Service | Above 200°C (400°F) for Class 150 or Above 400°C (750°F) |
| Low Temperature Service | Above -29°C (-20°F) |
| JIS Standards | 5K, 10K, 16K, 20K, 30K, 40K, 63K |
| Materials Used | Duplex & Super Duplex Steel, Stainless Steel, Carbon Steel, Alloy Steel, Inconel, Hastelloy, Copper Nickel, Cast Iron, Mild Steel, Wrought Iron |
| Thickness | NPS ≤ 18 |
Looking for High-Quality Industrial Metal Products?
Get in touch with our experts for competitive pricing, fast delivery, and customized solutions.
If you are looking for UNS S32760 Flanges suppliers, Steel Gems is ready to help. Contact us today for more details or to get a quick quote.
Steel Gems provides reliable supply of UNS S32760 Flanges to key industrial hubs across India, including Mumbai, Pune, Delhi, Chennai, Ahmedabad, and Hyderabad, while also catering to international markets such as the UAE, Saudi Arabia, Qatar, Oman, Malaysia, Singapore, Indonesia, and South Africa. Built for highly aggressive and high-pressure environments, these super duplex flanges deliver exceptional strength along with outstanding resistance to corrosion and pitting. They are widely used in industries like oil & gas, petrochemical processing, desalination plants, offshore platforms, and power generation facilities. With a strong logistics network, strict quality checks, and efficient delivery system, Steel Gems ensures consistent support for both large industrial projects and ongoing operational requirements.
UNS S32760 Flanges Super Duplex Steel Flanges Equivalent
| Parameter | Details |
|---|---|
| Standard | Super Duplex (UNS S32760 Flanges) |
| UNS | S32760 |
| Werkstoff Nr. | 1.4501 |
